Study 122106
Study 122106
Very flexible cable with an extremely good mechanical behaviour.
Withstands miscellaneous sterilisation process.
- Country ref. : Etude 122106
Description
Description
Standards
-
ProductNexans specification
1- CORE (A)
AWG 38 Silver plated copper wire.
FEP insulation
Diameter : 0.40 +/- 0.05 mm.
2- Filler
Assembly
16 Cores (A) + 1 Filler twisted
Nominal diameter : 1.90 mm
3- PTFE Tape
Nominal diameter : 1.96 mm
4- SHIELD
AWG 40 Tin plated copper braid
85% coverage
Diameter : 2.30 mm
5- Medical PVC Jacket
Diameter : 2.95 +/- 0.05 mm
Mechanical performances
Minimum bending radius : 5 x Overall diameter.
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Conductor material
Silvered copper
Conductor shape
Single wired
Construction type
Shielded and sheathed
Insulation
Fluor polymer
Dimensional characteristics
Dimensional characteristics
Wire diameter
0.4 mm
Outer Diameter
2.95 mm
Maximum outer diameter
3.0 mm
Approximate weight
12 g/m
Electrical characteristics
Electrical characteristics
Operating voltage
250 V
Mechanical characteristics
Mechanical characteristics
Cable flexibility
Very flexible
Usage characteristics
Usage characteristics
Maximum operating temperature
80 °C
Minimum operating temperature
-20 °C
Mechanical Resistance
Good mechanical resistance
