Study 132513
Study 132513
Very flexible cable with an extremely good mechanical behaviour.
Withstands miscellaneous sterilisation processes.
- Country ref. : Etude 132513
Description
Description
Standards
-
ProductNexans specification
1- Conductor
AWG 42 Silver plated copper alloy wire.
2- Insulation
Fluoropolymer
Nominal diameter : 0.26 mm
3- Shield
AWG 48 silver plated copper spiral shield
Nominal diameter : 0.32 mm
4- Jacket
Fluoropolymer
Diameter : 0.38 +/- 0.02 mm
Main Characteristics
Minimum bending radius : 5 x Overall diameter.
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Construction type
Shielded and sheathed
Conductor shape
Single wired
Conductor material
Silver coated copper
Insulation
Fluor polymer
Dimensional characteristics
Dimensional characteristics
Approximate weight
0.35 g/m
Outer Diameter
0.38 mm
Electrical characteristics
Electrical characteristics
Operating voltage
24 V
Mechanical characteristics
Mechanical characteristics
Cable flexibility
Very flexible
Usage characteristics
Usage characteristics
Maximum operating temperature
200 °C
Minimum operating temperature
-50 °C
RoHS compliant
Yes
