Study 133056
Description
Description
Standards
-
Product448-010-3-10; Nexans specification
Characteristics
Very flexible cable with an extremely good mechanical behaviour.
Withstands miscellaneous sterilisation processes.
CONSTRUCTION
1- CORE (A)
AWG 36 silver plated copper wire.
FEP insulation.
Diameter : 0.32 +/- 0.03 mm
AWG 44 silver plated copper helicoidal screen
Nominal diameter : 0.42 mm
FEP jacket
Diameter : 0.52 +/- 0.03 mm
2 Cores (A) twisted.
Nominal diameter : 1.02 mm
2- SHIELD
AWG 44 silver plated copper helicoidal screen.
Nominal diameter : 1.12 mm
6- JACKET
Suoer Polyamide
Diameter : 1.50 +/- 0.10 mm
Main Characteristics
Minimum bending radius : 5 x Overall diameter.
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Construction type
Shielded and sheathed
Conductor shape
Single wired
Conductor material
Silver coated copper
Insulation
FEP
Dimensional characteristics
Dimensional characteristics
Approximate weight
3.5 g/m
Outer Diameter
1.5 mm
Electrical characteristics
Electrical characteristics
Operating voltage
24 V
Mechanical characteristics
Mechanical characteristics
Cable flexibility
Very flexible
Usage characteristics
Usage characteristics
Maximum operating temperature
85 °C
Minimum operating temperature
-30 °C
RoHS compliant
Yes
